Kernel Module & Modprobe Security Check: Linux Guide

Every kernel module you load is code running with full ring-0 privilege. An out-of-tree module with a backdoor, a legitimate module with a known CVE, or an unwanted filesystem driver loaded automatically when the wrong USB stick appears — each is a path to root that bypasses every userspace defence you have. This guide covers the security-focused side of modprobe: signature verification, automatic load auditing, hard blacklisting, and post-boot lockdown.

What is loaded right now

lsmod                            # name, size, refcount, used-by
lsmod | wc -l                    # total module count
lsmod | awk '$3==0 {print $1}'   # loaded but unused (candidates for removal)
modinfo nf_tables | head          # description, parameters, signature, license

The "license" line in modinfo tells you whether the module taints the kernel. License: GPL is clean; License: Proprietary taints, which limits the support you can expect from upstream.

Signed modules and Secure Boot

Distribution kernels with Secure Boot enforce signature verification — only modules signed by a trusted key can load. Verify your host:

mokutil --sb-state                          # Secure Boot enabled?
cat /sys/kernel/security/lockdown            # current lockdown mode
dmesg | grep -E 'taint|signature|loaded kernel'
modinfo MODULE | grep -E '^sig_'

If lockdown is integrity or confidentiality, unsigned modules cannot be loaded at all — even by root. This is the recommended baseline for internet-facing servers.

Loading and unloading safely

sudo modprobe -v dummy                    # verbose; shows dependencies
sudo modprobe --dump-modversions /lib/modules/$(uname -r)/.../mod.ko
sudo modprobe -r dummy                    # unload, fails if in use
sudo dmesg -T | tail                       # kernel feedback after load

Always use modprobe rather than insmod — only modprobe resolves dependencies and respects modprobe.d configuration.

Persisting load and parameters

echo dummy | sudo tee /etc/modules-load.d/dummy.conf
echo 'options dummy numdummies=4' | sudo tee /etc/modprobe.d/dummy.conf
sudo update-initramfs -u                  # Debian/Ubuntu
sudo dracut --force                       # RHEL family

Hard-deny: blacklist plus install-false

Blacklist alone only stops automatic loading; an attacker can still modprobe the module manually. The combination of blacklist and install-redirect closes both:

# /etc/modprobe.d/CIS.conf
install cramfs    /bin/true
install freevxfs  /bin/true
install jffs2     /bin/true
install hfs       /bin/true
install hfsplus   /bin/true
install squashfs  /bin/true
install udf       /bin/true
install usb-storage /bin/true
install dccp      /bin/true
install sctp      /bin/true
install rds       /bin/true
install tipc      /bin/true
install firewire-core /bin/true
blacklist cramfs
blacklist freevxfs
blacklist jffs2
blacklist hfs
blacklist hfsplus
blacklist squashfs
blacklist udf
blacklist usb-storage
blacklist dccp
blacklist sctp
blacklist rds
blacklist tipc
blacklist firewire-core

Each entry closes a specific attack vector: rare filesystem drivers used by USB exploits, obscure protocols used in CVEs, and DMA-attack interfaces. The list is the CIS Linux Benchmark recommendation; apply, rebuild initramfs, reboot.

Post-boot lockdown

For appliances or any host where module loading should stop after boot:

echo 1 | sudo tee /proc/sys/kernel/modules_disabled
# or persistent:
echo 'kernel.modules_disabled = 1' | sudo tee /etc/sysctl.d/99-modules.conf

Once set, no module can be loaded or unloaded until reboot. Apply only after all expected modules are loaded; mistime it and you cannot load nf_conntrack when iptables decides it needs it.

Auditing module load events

# /etc/audit/rules.d/modules.rules
-w /sbin/insmod       -p x -k modules
-w /sbin/modprobe     -p x -k modules
-w /sbin/rmmod        -p x -k modules
-a always,exit -F arch=b64 -S init_module,delete_module,finit_module -k modules

sudo augenrules --load
sudo ausearch -k modules -ts today | head

Now every module load attempt — successful or not, automatic or manual — is recorded with the originating UID, parent process, and exact syscall arguments. This is the single most useful audit rule for catching kernel-rootkit installation.

Module integrity baseline

An attacker may replace a legitimate .ko file on disk and wait for next reboot. Defend by snapshotting hashes:

find /lib/modules/$(uname -r) -name '*.ko*' \
  -exec sha256sum {} + | sort > /var/lib/modules-baseline.sha256
# later:
diff /var/lib/modules-baseline.sha256 \
     <(find /lib/modules/$(uname -r) -name '*.ko*' -exec sha256sum {} + | sort)

Wrap into a daily cron and ship the diff to your log collector. Any non-empty diff outside an apt/dnf upgrade window is suspicious.

The audit script

#!/bin/bash
echo "== Loaded modules count =="
lsmod | tail -n +2 | wc -l
echo "== Tainted? =="
cat /proc/sys/kernel/tainted
echo "== Lockdown =="
cat /sys/kernel/security/lockdown 2>/dev/null || echo "n/a"
echo "== Modules-disabled =="
cat /proc/sys/kernel/modules_disabled
echo "== Recently loaded (audit) =="
ausearch -k modules -ts today 2>/dev/null | grep -c 'type=SYSCALL'
echo "== Unsigned loaded modules =="
for m in /sys/module/*/sections; do
  d=$(dirname "$m"); n=$(basename "$d")
  modinfo "$n" 2>/dev/null | grep -q '^sig_id' || echo "  $n"
done | head -10

Common pitfalls

• Blacklisting usb-storage on a server, then needing it for an emergency backup; document an "emergency unblock" runbook before locking down.
• Setting kernel.modules_disabled=1 in sysctl too early; if a service later requires a not-yet-loaded module the host hangs.
• Forgetting initramfs rebuild after blacklist changes — the unwanted module loads anyway from the early ramdisk.
• Using install MODULE /bin/false instead of /bin/true; /bin/false exits non-zero and pollutes logs.

Module security is configured once at provisioning, validated weekly, and forgotten the rest of the year — until it saves you. Apply the CIS deny list, sign in audit rules, snapshot hashes, and your kernel attack surface shrinks dramatically without losing a single feature you actually use.
