ARP Table Monitoring: Detect MAC Spoofing and Network Anomalies on Linux

The ARP table maps every IPv4 address you talk to into a MAC address — and an attacker who can poison it sees, modifies, or drops your traffic. ARP spoofing is one of the oldest attacks in networking and remains effective on flat Layer 2 networks because the protocol has no authentication. Linux exposes the ARP cache through several tools; this guide walks through the audit techniques that detect spoofing, duplicate IPs, and rogue devices on a network segment.

The modern ARP commands

arp is deprecated; ip neigh from iproute2 is the supported replacement:

ip neigh show                          # current ARP/NDP table
ip neigh show dev eth0                 # one interface
ip -s neigh                            # with statistics
arp -an                                # legacy form, still works
ip neigh flush all                     # nuke the cache (forces re-learn)

Each entry shows IP, device, MAC, and a state: REACHABLE, STALE, DELAY, PROBE, FAILED. Healthy hosts have most entries reachable; many FAILED entries indicate aggressive scanning or a broken peer.

Detecting duplicate IPs

Two devices with the same IP cause ARP to flap between MACs — the symptom is intermittent connectivity blamed on "the network":

arping -c 5 -D -I eth0 192.0.2.10        # duplicate-address detection
ip neigh | awk '{print $1}' | sort | uniq -d
sudo arpwatch -i eth0 -d                  # live monitoring of address changes

arping -D sends an ARP request specifically asking "does anyone else claim this IP?" — the standard way to verify a static IP is unused before assigning it.

Detecting MAC spoofing

The classic ARP-spoofing pattern: an attacker sends gratuitous ARP replies claiming the gateway's IP belongs to their MAC. Symptoms in your ARP table:

• The gateway's MAC suddenly changes.
• The same MAC appears for multiple IPs.
• A new MAC OUI you do not recognise becomes the gateway.

ip neigh | awk '{print $5}' | sort | uniq -c | sort -rn | head
ip neigh | awk '{print $5}' | sort -u | wc -l         # unique MACs seen
sudo arpwatch -f /var/lib/arpwatch/eth0.dat -i eth0   # log every change

Continuous monitoring with arpwatch

arpwatch is the dedicated tool for this. It maintains a database of (IP, MAC) pairings and emails when one changes:

sudo apt install arpwatch
sudo systemctl enable --now arpwatch
sudo journalctl -u arpwatch --since today
sudo cat /var/lib/arpwatch/arp.dat | head

Configure the recipient address in /etc/arpwatch/eth0.iface or via systemd unit override. Every "new station" or "changed ethernet address" event becomes an email — perfect for small networks; pipe to your SIEM for larger fleets.

Static ARP entries for critical peers

The most effective defence: hard-code the gateway and database server MACs so spoofed replies are ignored:

sudo ip neigh add 192.0.2.1 lladdr aa:bb:cc:dd:ee:ff dev eth0 nud permanent
ip neigh show 192.0.2.1
# Persist via /etc/network/interfaces post-up or NetworkManager dispatcher

Drawback: if the gateway hardware is replaced, you must update every host. For data-centre environments where MACs do not change unexpectedly, the trade-off is worth it for the most critical peers.

Sysctl hardening

# /etc/sysctl.d/99-arp.conf
net.ipv4.conf.all.arp_ignore = 1
net.ipv4.conf.default.arp_ignore = 1
net.ipv4.conf.all.arp_announce = 2
net.ipv4.conf.default.arp_announce = 2
net.ipv4.conf.all.drop_gratuitous_arp = 1
net.ipv4.conf.default.drop_gratuitous_arp = 1

arp_ignore=1 only answers ARP requests for an IP actually configured on the receiving interface. arp_announce=2 uses the best-matching source IP. drop_gratuitous_arp=1 ignores unsolicited ARP replies — the primary spoofing vector.

Switch-side dynamic ARP inspection

The strongest mitigation lives on the switch, not the host: managed switches support DHCP snooping plus Dynamic ARP Inspection (DAI), which validates every ARP packet against the snooping binding table. Coordinate with your network team — this single feature defeats most ARP attacks regardless of host configuration.

Audit script

#!/bin/bash
echo "== ARP table summary =="
total=$(ip neigh | wc -l)
unique_macs=$(ip neigh | awk '{print $5}' | sort -u | wc -l)
failed=$(ip neigh | grep -c FAILED)
echo "  total entries: $total"
echo "  unique MACs:   $unique_macs"
echo "  failed:        $failed"

echo
echo "== Duplicate IPs =="
ip neigh | awk '{print $1}' | sort | uniq -d

echo
echo "== Macs claiming multiple IPs =="
ip neigh | awk '{print $5, $1}' | sort -u | awk '{m[$1]++} END {for (k in m) if (m[k]>1) print m[k], k}' | sort -rn | head

echo
echo "== Gateway MAC =="
gw=$(ip route | awk '/^default/ {print $3}')
ip neigh show "$gw"

echo
echo "== Recent arpwatch events =="
journalctl -u arpwatch --since '24 hours ago' | grep -E 'new (station|activity)|changed' | tail -10

Wireless caveats

Wi-Fi has additional MAC-layer protection (WPA2/3 4-way handshake) but the kernel ARP cache still operates the same. Captive portals and open Wi-Fi remain vulnerable. Avoid sensitive operations on untrusted networks regardless of host hardening.

Common pitfalls

• Trusting that "we have a switch with port security" without enabling DAI — port security alone does not stop ARP spoofing.
• Setting all gateway entries to permanent then forgetting about them when hardware refreshes.
• Running arpwatch but not actually reading the email — the alert is only useful if someone investigates.
• Disabling gratuitous ARP entirely and breaking VRRP, keepalived, or container-runtime IP failover.

ARP is unauthenticated, ancient, and on every Layer 2 network you connect to. Five minutes setting up arpwatch, hardening sysctls, and pinning critical MAC entries closes a class of MitM attacks that pen testers love and defenders rarely look at. Make it part of your network hardening baseline.
