Prometheus and Grafana Setup: Complete Monitoring Stack for Linux Servers

Monitoring is essential for maintaining healthy infrastructure. Prometheus and Grafana together form the most popular open-source monitoring stack, used by organizations from startups to enterprises. This guide walks you through setting up a production-ready monitoring system on Linux.

Architecture Overview

The monitoring stack consists of:

• Prometheus: Time-series database that scrapes metrics from targets
• Node Exporter: Exposes Linux system metrics (CPU, memory, disk, network)
• Grafana: Visualization platform for creating dashboards
• Alertmanager: Handles alerts from Prometheus and routes notifications

Installing Prometheus

# Create user
sudo useradd --no-create-home --shell /bin/false prometheus

# Download and install
cd /tmp
wget https://github.com/prometheus/prometheus/releases/download/v2.50.0/prometheus-2.50.0.linux-amd64.tar.gz
tar xzf prometheus-2.50.0.linux-amd64.tar.gz
sudo cp prometheus-2.50.0.linux-amd64/{prometheus,promtool} /usr/local/bin/

# Create directories
sudo mkdir -p /etc/prometheus /var/lib/prometheus
sudo chown prometheus:prometheus /var/lib/prometheus

Prometheus Configuration

# /etc/prometheus/prometheus.yml
global:
  scrape_interval: 15s
  evaluation_interval: 15s

alerting:
  alertmanagers:
    - static_configs:
        - targets: ['localhost:9093']

rule_files:
  - "alert_rules.yml"

scrape_configs:
  - job_name: 'prometheus'
    static_configs:
      - targets: ['localhost:9090']

  - job_name: 'node_exporter'
    static_configs:
      - targets: ['localhost:9100']

Installing Node Exporter

wget https://github.com/prometheus/node_exporter/releases/download/v1.7.0/node_exporter-1.7.0.linux-amd64.tar.gz
tar xzf node_exporter-1.7.0.linux-amd64.tar.gz
sudo cp node_exporter-1.7.0.linux-amd64/node_exporter /usr/local/bin/

# Create systemd service
sudo tee /etc/systemd/system/node_exporter.service <<EOF
[Unit]
Description=Node Exporter
After=network.target

[Service]
User=prometheus
ExecStart=/usr/local/bin/node_exporter

[Install]
WantedBy=multi-user.target
EOF

sudo systemctl daemon-reload
sudo systemctl enable --now node_exporter

Installing Grafana

# Add Grafana repository
sudo apt install -y software-properties-common
wget -q -O - https://packages.grafana.com/gpg.key | sudo apt-key add -
echo "deb https://packages.grafana.com/oss/deb stable main" | sudo tee /etc/apt/sources.list.d/grafana.list

sudo apt update
sudo apt install grafana

sudo systemctl enable --now grafana-server

Creating Dashboards

After connecting Prometheus as a data source in Grafana:

1. Import the Node Exporter Full dashboard (ID: 1860) for comprehensive system monitoring
2. Create custom panels with PromQL queries
3. Set up variables for multi-server dashboards

Essential PromQL Queries

# CPU Usage Percentage
100 - (avg by(instance)(rate(node_cpu_seconds_total{mode="idle"}[5m])) * 100)

# Memory Usage Percentage
(1 - node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes) * 100

# Disk Usage Percentage
(1 - node_filesystem_avail_bytes{mountpoint="/"} / node_filesystem_size_bytes{mountpoint="/"}) * 100

# Network Traffic (bytes/sec)
rate(node_network_receive_bytes_total{device="eth0"}[5m])

Alert Rules

# /etc/prometheus/alert_rules.yml
groups:
  - name: server_alerts
    rules:
      - alert: HighCPUUsage
        expr: 100 - (avg by(instance)(rate(node_cpu_seconds_total{mode="idle"}[5m])) * 100) > 80
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "High CPU usage on {{ $labels.instance }}"

      - alert: DiskSpaceLow
        expr: (1 - node_filesystem_avail_bytes{mountpoint="/"} / node_filesystem_size_bytes{mountpoint="/"}) * 100 > 85
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "Disk space low on {{ $labels.instance }}"

Production Best Practices

1. Use persistent storage for Prometheus data with appropriate retention settings
2. Set up Alertmanager with email, Slack, or PagerDuty notifications
3. Secure Grafana with HTTPS and strong authentication
4. Implement recording rules for frequently used queries
5. Monitor the monitoring system itself
6. Use federation for multi-datacenter setups

A well-configured monitoring stack gives you visibility into your infrastructure and helps you detect and resolve issues before they impact users. Start with basic metrics and gradually expand your monitoring coverage.
