Prometheus + Grafana Monitoring Stack: Complete Setup Guide

If you're running servers without monitoring, you're flying blind. Prometheus collects metrics, Grafana visualizes them, and Alertmanager notifies you when things go wrong. Here's how to set up all three.

Docker Compose Deployment

version: '3.8'
services:
  prometheus:
    image: prom/prometheus:latest
    ports:
      - "9090:9090"
    volumes:
      - ./prometheus.yml:/etc/prometheus/prometheus.yml
      - ./alert.rules.yml:/etc/prometheus/alert.rules.yml
      - prometheus_data:/prometheus
    command:
      - '--config.file=/etc/prometheus/prometheus.yml'
      - '--storage.tsdb.retention.time=30d'
    restart: unless-stopped

  grafana:
    image: grafana/grafana:latest
    ports:
      - "3000:3000"
    environment:
      - GF_SECURITY_ADMIN_PASSWORD=your-secure-password
      - GF_INSTALL_PLUGINS=grafana-clock-panel
    volumes:
      - grafana_data:/var/lib/grafana
    restart: unless-stopped

  node-exporter:
    image: prom/node-exporter:latest
    ports:
      - "9100:9100"
    volumes:
      - /proc:/host/proc:ro
      - /sys:/host/sys:ro
      - /:/rootfs:ro
    command:
      - '--path.procfs=/host/proc'
      - '--path.sysfs=/host/sys'
    restart: unless-stopped

  alertmanager:
    image: prom/alertmanager:latest
    ports:
      - "9093:9093"
    volumes:
      - ./alertmanager.yml:/etc/alertmanager/alertmanager.yml
    restart: unless-stopped

volumes:
  prometheus_data:
  grafana_data:

Essential PromQL Queries

# CPU usage percentage
100 - (avg(rate(node_cpu_seconds_total{mode="idle"}[5m])) * 100)

# Memory usage percentage
(1 - node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes) * 100

# Disk usage percentage
(1 - node_filesystem_avail_bytes{mountpoint="/"} / node_filesystem_size_bytes{mountpoint="/"}) * 100

# Network received bytes/sec
rate(node_network_receive_bytes_total{device="eth0"}[5m])

# HTTP request rate
rate(http_requests_total[5m])

# HTTP error rate (5xx)
rate(http_requests_total{status=~"5.."}[5m]) / rate(http_requests_total[5m]) * 100

# 95th percentile response time
histogram_quantile(0.95, rate(http_request_duration_seconds_bucket[5m]))

Alert Rules

# alert.rules.yml
groups:
- name: server_alerts
  rules:
  - alert: HighCPUUsage
    expr: 100 - (avg(rate(node_cpu_seconds_total{mode="idle"}[5m])) * 100) > 80
    for: 5m
    labels:
      severity: warning
    annotations:
      summary: "High CPU usage detected"
      description: "CPU usage is above 80% for 5 minutes"

  - alert: HighMemoryUsage
    expr: (1 - node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes) * 100 > 90
    for: 5m
    labels:
      severity: critical

  - alert: DiskSpaceLow
    expr: (1 - node_filesystem_avail_bytes{mountpoint="/"} / node_filesystem_size_bytes{mountpoint="/"}) * 100 > 85
    for: 10m
    labels:
      severity: warning

A properly configured monitoring stack pays for itself the first time it catches an issue before your users do. Start with the basics — CPU, memory, disk — then add application-specific metrics as your system grows.
